Aqua Pulse Bottleless Water Cooler Overview

The Aqua Pulse Bottleless Water Cooler is a plumbed-in hydration system designed for modern homes and offices. It provides a continuous supply of filtered hot and cold water by connecting directly to your mains water supply.

Aqua Pulse Bottleless Water Cooler featuring a high-gloss white finish and brushed steel sides

To operate at peak performance, this cooler requires a compatible filtration setup. The system integrates seamlessly with our swing-and-twist water filters, allowing for simple, tool-free maintenance without the need to isolate the mains water.

Key Features & Technical Specifications

This bottleless cooler is engineered for heavy-duty durability and precise temperature control. Below are the core hardware specifications and component details.

Cold Tank: Features a 3.3-liter capacity constructed from highly polished Type 304 stainless steel for rapid and efficient chilling.
Hot Tank: Includes a 1.8-liter Type 304 stainless steel tank powered by a 500-watt sheathed heater, complete with a rear-mounted on/off switch.
Cabinet Aesthetic: Designed with a white high-gloss ABS front panel combined with brushed steel silver high-polymer sides.
Dispensing Taps: Equipped with NSF-approved, self-closing polypropylene push taps. The hot water tap includes a standard integrated safety lock.
Internal Components: Utilizes a dual float assembly system for automatic shutoff, a hermetically sealed compressor, and a quiet, air-cooled condenser.

Cooling & Heating Performance

This system is designed to handle high-volume hydration in active environments. It reliably delivers up to 22 cups per hour of crisp cold water (approximately 4-10°C) and 15 cups per hour of hot water (approximately 84-89°C) suitable for teas and instant coffees.

Installation & Warranty Requirements

The Aqua Pulse cooler is supported by a comprehensive 36-month warranty covering parts and labor. To maintain this warranty's validity, the unit must be installed by a qualified professional according to local plumbing regulations, which strictly requires the fitting of a Pressure Limiting Valve.

Non-Plumbed Alternatives

For locations where a direct mains water connection is not feasible, standalone bottled water coolers provide a highly effective alternative. These units are available in off-white and pure white finishes, with both hot/cold and cold/ambient configurations to match specific environmental requirements.

Frequently Asked Questions

Does this bottleless cooler require professional installation?

Yes. To ensure optimal performance and maintain the 36-month warranty, a qualified professional must install this plumbed-in unit in accordance with local plumbing codes.

What type of water filters are compatible with this cooler?

This unit is compatible with our "swing & twist" filter systems, which are available in single, twin, or triple setups. These water filters allow for easy replacement without turning off the main water supply.

Is there a safety feature on the hot water tap?

Yes. The Aqua Pulse Bottleless Water Cooler features an NSF-approved safety mechanism on the hot water tap to prevent accidental dispensing, making it safe for shared spaces.
